Specifications

Model                                    CS-H3-R100-1J5WKFL

General

Dimensions                       75.5 ?? 75.5 ?? 155 mm (2.97 ?? 2.97 ?? 6.10 inch)
Package Dimensions         227 ?? 100 ?? 92 mm (8.94 ?? 3.94 ?? 3.62 inch)
Weight                               Net weight: 433 g (15.27 oz) With package: 652 g (23.00 oz)
IP Grade                            IP67
Operating Conditions      -30 ??C ~ 60 ??C (-22 ??F ~ 140 ??F ) Humidity 95% or less (non-condensing)

Camera

Image Sensor                   1/2.7???Progressive Scan CMOS
Shutter Speed                  Self-adaptive shutter
Lens                                  2.8mm @ F2.0, viewing angle: 114?? (Diagonal), 96?? (Horizontal), 51?? (Vertical) 4mm @ F2.0, viewing                                            angle:95?? (Diagonal), 80?? (Horizontal), 42?? (Vertical)
Minimum Illumination    0.01 lux @ (F2.0, AGC ON), 0 Lux with IR
Lens Mount                      M12
Day / Night Switch           IR-Cut filter with auto-switching
DNR                                  3D DNR
WDR                                  Digital WDR
BLC                                    Supports
IR Night Vision Distance   Up to 98 ft / 30 m

Video & Audio

Max. Resolution             2880 ?? 1620 pixels
Frame Rate                     Max: 30fps; Self-Adaptive during network transmission
Video Compression        H.265 / H.264
Video Bit Rate                 Quad HD+; Full HD; HD; Standard. Adaptive bit rate.
Audio Bit Rate                Self-Adaptive
Max. Bitrate                   4 Mbps

Network

Wi-Fi Standard                IEEE802.11b, 802.11g, 802.11n
Frequency Range           2.4 GHz ~ 2.4835 GHz
Channel Bandwidth       Supports 20 MHz
Security                           64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
Transmission Rate         11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps
Wi-Fi Pairing                   AP Pairing
Protocol                          EZVIZ Cloud Proprietary Protocol
Interface Protocol          EZVIZ Cloud Proprietary Protocol
Wired Network              RJ45 ?? 1 (10M / 100M Adaptive Ethernet Port)

Function

Detection                          AI-Powered Human / Vehicle Shape Detection, Waving-Hand Detection, Motion Detection
Customized Alert Area    Supports
Integration                       Works with Alexa, Google Assistant, IFTTT
General Function             Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark

Storage

Local Storage                  Supports microSD card (Up to 512 GB)
Cloud Storage                 Supports EZVIZ CloudPlay storage (Subscription required)

Power

Wiring                             Hard-Wired
Power Supply                 DC 12V / 1A
Power Consumption      Max. 8W

In the box

In the box      - EZVIZ H3 3K Camera
                       - Drill Template
                       - Screw Kit
                       - Waterproof Kit
                       - Power Adapter
                       - Regulatory Information
                       - Quick Start Quide
