Hikvision 8 Channel 1080P Digital Video Recorder, Lite 1U, Up To 2MP Support, H.265 Video Compression, 32 Kbps to 4 Mbps Video Bitrate, 1 SATA Interface, Black | DS-7208HGHI-K1-S
Model :
SKU : DS-7208HGHI-K1-S LITE
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Hikvision 8 Channel 1080P Digital Video Recorder, Lite 1U, Up To 2MP Support, H.265 Video Compression, 32 Kbps to 4 Mbps Video Bitrate, 1 SATA Interface, Black | DS-7208HGHI-K1-S
| Motion Detection 2.0 | ||
| Human/Vehicle Analysis | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; | |
| Quick search by object or event type is supported; | ||
| Recording | ||
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 | |
| Encoding Resolution | For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF For 720p stream access: 720p/WD1/4CIF/VGA/CIF For SD stream access: WD1/4CIF/VGA/CIF |
|
| Frame Rate | Main stream: For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) Sub-stream: For 1080p and 720p stream access CIF/QVGA@15 fps For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N) |
|
| Video Bitrate | 32 Kbps to 4 Mbps | |
| Stream Type | Video, Video & Audio | |
| Audio Compression | G.711u | |
| Audio Bitrate | 64 Kbps | |
| Video And Audio | ||
| IP Video Input | 2-ch (up to 10-ch) Up to 5 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
|
| Analog Video Input | 8-ch BNC interface (1.0 Vp-p, 75 ??), supporting coaxitron connection |
|
| HDTVI Input | 1080p25, 1080p30, 720p25, 720p30 | |
| AHD Input | 1080p25, 1080p30, 720p25, 720p30 | |
| HDCVI Input | 1080p25, 1080p30, 720p25, 720p30 | |
| CVBS Input | Support | |
| HDMI Output | 1-ch, 1920 ?? 1080/60Hz, 1280 ?? 1024/60Hz, 1280 ?? 720/60Hz | |
| VGA Output | 1-ch, 1920 ?? 1080/60Hz, 1280 ?? 1024/60Hz, 1280 ?? 720/60Hz | |
| Video Output Mode | HDMI/VGA simultaneous output | |
| Audio Input | 1-ch RCA (2.0 Vp-p, 1 K??) 8-ch via coaxial cable |
|
| Audio Output | 1-ch, RCA (Linear, 1 K??) | |
| Two-Way Audio | Reuse the first audio input | |
| Synchronous Playback | 8-ch | |
| Network | ||
| Remote Connection | 64 | |
| Network Protocol | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP???, HTTPS | |
| Total Bandwidth | 72 Mbps | |
| Network Interface | 1, RJ45 10/100 Mbps self-adaptive Ethernet interface | |
| Auxiliary Interface | SATA 1 SATA interface |
|
| Capacity | Up to 4 TB capacity for each disk | |
| USB Interface | Rear panel: 2 ?? USB 2.0 | |
| Alarm In/Out | N/A | |
| General | ||
| Power Supply | 12 VDC, 1.5 A | |
| Consumption | ??? 17 W (without HDD) | |
| Working Temperature | -10 ??C to 55 ??C (14 ??F to +31 ??F) | |
| Working Humidity | 10% to 90% | |
| Dimension (W ?? D ?? H) | 260 ?? 222 ?? 45 mm (10.2 ?? 8.7 ?? 1.8 inch) | |
| Weight | ??? 1 kg (without HDD, 2.2 lb.) |
Specification
Hikvision 8 Channel 1080P Digital Video Recorder, Lite 1U, Up To 2MP Support, H.265 Video Compression, 32 Kbps to 4 Mbps Video Bitrate, 1 SATA Interface, Black | DS-7208HGHI-K1-S
| Motion Detection 2.0 | ||
| Human/Vehicle Analysis | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; | |
| Quick search by object or event type is supported; | ||
| Recording | ||
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 | |
| Encoding Resolution | For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF For 720p stream access: 720p/WD1/4CIF/VGA/CIF For SD stream access: WD1/4CIF/VGA/CIF |
|
| Frame Rate | Main stream: For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) Sub-stream: For 1080p and 720p stream access CIF/QVGA@15 fps For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N) |
|
| Video Bitrate | 32 Kbps to 4 Mbps | |
| Stream Type | Video, Video & Audio | |
| Audio Compression | G.711u | |
| Audio Bitrate | 64 Kbps | |
| Video And Audio | ||
| IP Video Input | 2-ch (up to 10-ch) Up to 5 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
|
| Analog Video Input | 8-ch BNC interface (1.0 Vp-p, 75 ??), supporting coaxitron connection |
|
| HDTVI Input | 1080p25, 1080p30, 720p25, 720p30 | |
| AHD Input | 1080p25, 1080p30, 720p25, 720p30 | |
| HDCVI Input | 1080p25, 1080p30, 720p25, 720p30 | |
| CVBS Input | Support | |
| HDMI Output | 1-ch, 1920 ?? 1080/60Hz, 1280 ?? 1024/60Hz, 1280 ?? 720/60Hz | |
| VGA Output | 1-ch, 1920 ?? 1080/60Hz, 1280 ?? 1024/60Hz, 1280 ?? 720/60Hz | |
| Video Output Mode | HDMI/VGA simultaneous output | |
| Audio Input | 1-ch RCA (2.0 Vp-p, 1 K??) 8-ch via coaxial cable |
|
| Audio Output | 1-ch, RCA (Linear, 1 K??) | |
| Two-Way Audio | Reuse the first audio input | |
| Synchronous Playback | 8-ch | |
| Network | ||
| Remote Connection | 64 | |
| Network Protocol | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP???, HTTPS | |
| Total Bandwidth | 72 Mbps | |
| Network Interface | 1, RJ45 10/100 Mbps self-adaptive Ethernet interface | |
| Auxiliary Interface | SATA 1 SATA interface |
|
| Capacity | Up to 4 TB capacity for each disk | |
| USB Interface | Rear panel: 2 ?? USB 2.0 | |
| Alarm In/Out | N/A | |
| General | ||
| Power Supply | 12 VDC, 1.5 A | |
| Consumption | ??? 17 W (without HDD) | |
| Working Temperature | -10 ??C to 55 ??C (14 ??F to +31 ??F) | |
| Working Humidity | 10% to 90% | |
| Dimension (W ?? D ?? H) | 260 ?? 222 ?? 45 mm (10.2 ?? 8.7 ?? 1.8 inch) | |
| Weight | ??? 1 kg (without HDD, 2.2 lb.) |
