Hikvision DS-2CD2621G0-I(Z) 2 MP WDR Varifocal Bullet Network Camera, Efficient H.265+, ,HD Video, EXIR, Weatherproof, Audio/Alarm (Optional), Water and dust resistant (IP67)
Model :
SKU : DS-2CD2621GO-IZ
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Hikvision DS-2CD2621G0-I(Z) 2 MP WDR Varifocal Bullet Network Camera, Efficient H.265+, ,HD Video, EXIR, Weatherproof, Vari-Focal Lens, Audio/Alarm (Optional), Water and dust resistant (IP67)
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Max. Resolution | 1920 ?? 1080 |
| Min. Illumination | Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: 0?? to 360??, tilt: 0?? to 100??, rotation: 0?? to 360?? |
| Lens Type | Varifocal Lens, motorized lens, 2.8 to 12 mm |
| Focal Length & FOV | 2.8 to 12 mm: horizontal FOV 94?? to 36??, vertical FOV 50?? to 20??, diagonal FOV 109?? to 42?? |
| Lens Mount | ??14 |
| Iris Type | Fixed |
| Aperture | F1.6 |
| Illuminator | Supplement Light Type: IR Supplement Light Range: Up to 60 m IR Wavelength: 850 nm |
| Video | Main Stream: 50 Hz: 25 fps (1920 ?? 1080, 1280 ?? 720) 60 Hz: 30 fps (1920 ?? 1080, 1280 ?? 720) Sub-Stream: 50 Hz: 25 fps (640 ?? 480, 640 ?? 360 ) 60 Hz: 30 fps (640 ?? 480, 640 ?? 360 ) Video Compression: Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Video Bit Rate: 32 Kbps to 8 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile |
| Region Of Interest (ROI) | 1 fixed region for main stream |
| Audio | Audio Compression: -S: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC Audio Bit Rate: -S: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) Audio Sampling Rate: -S: 8 kHz/16 kHz Environment Noise Filtering: -S: Yes |
| Network | Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP???, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour Simultaneous Live View: Up to 6 channels API: Open Network Video Interface, ISAPI User/Host: Up to 32 users. 3 levels: administrator, operator and user Client: iVMS-4200, Hik-Connect Web Browser: Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Image | Image Settings: Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser Day/Night Switch: Auto, Schedule, Day, Night Wide Dynamic Range (WDR): 120 dB Image Enhancement: BLC, 3D DNR |
| Interface | Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port On-Board Storage: Built-in memory card slot, support microSD card, up to 256 GB Audio: -S: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 K??, interface type: non-equilibrium 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 ??, interface type: non-equilibrium |
| Alarm | -S: 1 input,1 output, (max. 12 VDC, 30 mA) |
| Reset Key | Yes |
| Event | Basic Event: Motion detection, video tampering alarm, exception Smart Event: Line crossing detection, intrusion detection Linkage: -S: Upload to FTP, notify surveillance center, send email, upload to memory card, trigger recording, trigger capture, audible warning, trigger alarm output |
| General | Power: 12 VDC ?? 25%, 0.9 A, max. 11 W, ??5.5 mm coaxial power plug PoE: (802.3af, Class 3, 36 V to 57 V), 0.23 A to 0.36 A, max. 12.9 W Material: Metal Dimension: ??105 mm ?? 294.5 mm (4.1" ?? 11.6") Package Dimension: 386 mm ?? 156 mm ?? 155 mm (15.2" ?? 6.1" ?? 6.1") Weight: Approx. 1050 g (2.3 lb.) With Package Weight: Approx. 1500 g (3.3 lb.) Storage Conditions: -30 ??C to +60 ??C (-22 ??F to +140 ??F). Humidity 95% or less (non-condensing) Startup And Operating Conditions: -30 ??C to +60 ??C (-22 ??F to +140 ??F), humidity 95% or less (non-condensing) Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian General Function: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter Approval: EMC: FCC SDoC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; RCM: AS/NZS CISPR 32: 2015; IC VoC: ICES-003: Issue 6, 2016; KC: KN 32: 2015, KN 35: 2015 Safety: UL: UL 60950-1; CB: IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014; CE-LVD: EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014; BIS: IS 13252(Part 1):2010+A1:2013+A2:2015 Environment: CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; Reach: Regulation (EC) No 1907/2006 Protection: IP67: IEC 60529-2013 |
Specification
Hikvision DS-2CD2621G0-I(Z) 2 MP WDR Varifocal Bullet Network Camera, Efficient H.265+, ,HD Video, EXIR, Weatherproof, Vari-Focal Lens, Audio/Alarm (Optional), Water and dust resistant (IP67)
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Max. Resolution | 1920 ?? 1080 |
| Min. Illumination | Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: 0?? to 360??, tilt: 0?? to 100??, rotation: 0?? to 360?? |
| Lens Type | Varifocal Lens, motorized lens, 2.8 to 12 mm |
| Focal Length & FOV | 2.8 to 12 mm: horizontal FOV 94?? to 36??, vertical FOV 50?? to 20??, diagonal FOV 109?? to 42?? |
| Lens Mount | ??14 |
| Iris Type | Fixed |
| Aperture | F1.6 |
| Illuminator | Supplement Light Type: IR Supplement Light Range: Up to 60 m IR Wavelength: 850 nm |
| Video | Main Stream: 50 Hz: 25 fps (1920 ?? 1080, 1280 ?? 720) 60 Hz: 30 fps (1920 ?? 1080, 1280 ?? 720) Sub-Stream: 50 Hz: 25 fps (640 ?? 480, 640 ?? 360 ) 60 Hz: 30 fps (640 ?? 480, 640 ?? 360 ) Video Compression: Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Video Bit Rate: 32 Kbps to 8 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile |
| Region Of Interest (ROI) | 1 fixed region for main stream |
| Audio | Audio Compression: -S: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC Audio Bit Rate: -S: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) Audio Sampling Rate: -S: 8 kHz/16 kHz Environment Noise Filtering: -S: Yes |
| Network | Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP???, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour Simultaneous Live View: Up to 6 channels API: Open Network Video Interface, ISAPI User/Host: Up to 32 users. 3 levels: administrator, operator and user Client: iVMS-4200, Hik-Connect Web Browser: Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Image | Image Settings: Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser Day/Night Switch: Auto, Schedule, Day, Night Wide Dynamic Range (WDR): 120 dB Image Enhancement: BLC, 3D DNR |
| Interface | Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port On-Board Storage: Built-in memory card slot, support microSD card, up to 256 GB Audio: -S: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 K??, interface type: non-equilibrium 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 ??, interface type: non-equilibrium |
| Alarm | -S: 1 input,1 output, (max. 12 VDC, 30 mA) |
| Reset Key | Yes |
| Event | Basic Event: Motion detection, video tampering alarm, exception Smart Event: Line crossing detection, intrusion detection Linkage: -S: Upload to FTP, notify surveillance center, send email, upload to memory card, trigger recording, trigger capture, audible warning, trigger alarm output |
| General | Power: 12 VDC ?? 25%, 0.9 A, max. 11 W, ??5.5 mm coaxial power plug PoE: (802.3af, Class 3, 36 V to 57 V), 0.23 A to 0.36 A, max. 12.9 W Material: Metal Dimension: ??105 mm ?? 294.5 mm (4.1" ?? 11.6") Package Dimension: 386 mm ?? 156 mm ?? 155 mm (15.2" ?? 6.1" ?? 6.1") Weight: Approx. 1050 g (2.3 lb.) With Package Weight: Approx. 1500 g (3.3 lb.) Storage Conditions: -30 ??C to +60 ??C (-22 ??F to +140 ??F). Humidity 95% or less (non-condensing) Startup And Operating Conditions: -30 ??C to +60 ??C (-22 ??F to +140 ??F), humidity 95% or less (non-condensing) Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian General Function: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter Approval: EMC: FCC SDoC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; RCM: AS/NZS CISPR 32: 2015; IC VoC: ICES-003: Issue 6, 2016; KC: KN 32: 2015, KN 35: 2015 Safety: UL: UL 60950-1; CB: IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014; CE-LVD: EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014; BIS: IS 13252(Part 1):2010+A1:2013+A2:2015 Environment: CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; Reach: Regulation (EC) No 1907/2006 Protection: IP67: IEC 60529-2013 |
