Hikvision DS-7608NI-M2 M Series 8K Non-PoE NVR, Up to 8-ch IP camera inputs, Up to 128 Mbps incoming bandwidth, HDMI & VGA, Up to 2 SATA interfaces for HDD, Smart & POS Functions, 2 self-adaptive 10/100/1000 Mbps Ethernet, Supports Solar-powered camera

IP Video Input

• 8-ch
• Up to 32 MP resolution
• *: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.

Incoming Bandwidth

128 Mbps

Outgoing Bandwidth

256 Mbps

HDMI Output

• 8K (7680 ?? 4320)/30Hz, 4K (3840 ?? 2160)/60Hz, 4K (3840 ?? 2160)/30Hz, 2K (2560 ?? 1440)/60Hz, 1920 ?? 1080/60Hz

VGA Output

1920 ?? 1080/60Hz

Video Output Mode

HDMI/VGA independent output

CVBS Output

1-ch, BNC (1.0 Vp-p, 75 ??), resolution: PAL: 704 ?? 576, NTSC: 704 ?? 480

Audio Output

1-ch, RCA (Linear, 1 K??)

Two-Way Audio

1-ch, RCA (2.0 Vp-p, 1 K??, using the audio input)

Decoding

• Decoding Format: H.265+/H.265/H.264+/H.264
• Recording Resolution: 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF
• *: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.

Synchronous Playback

8-ch

Decoding Capability

2-ch@32 MP (30 fps)+2-ch@8MP???30fps???/10-ch@8 MP (30 fps)/20-ch@4 MP (30 fps)/40-ch@1080p (30 fps)

Dual-Stream Recording

Support

Stream Type

Video, Video & Audio

Audio Compression

G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2

Network

Remote Connection

128

Network Protocol

TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP???, HTTP, HTTPS

Network Interface

2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

Auxiliary Interface

• SATA: 2 SATA interfaces
• Capacity: Up to 16 TB capacity for each HDD
• Alarm In/Out: 4/1
• USB Interface: Front panel: 1 ?? USB 2.0; Rear panel: 1 ?? USB 3.0

General

Power Supply

12 VDC, 3.33 A

Consumption

??? 15 W (without HDD)

Working Temperature

-10 ??C to 55 ??C (14 ??F to 131 ??F)

Working Humidity

10% to 90%

Dimension (W ?? D ?? H)

385 ?? 315?? 52 mm (15.2" ?? 12.4" ?? 2.0")

Weight

??? 3 kg (without HDD, 2.2 lb.)

Certification

• FCC: Part 15 Subpart B, ANSI C63.4-2014
• CE: EN 55032:2015+A1:2020, ENIEC61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020
