Hikvision DS-7716NXI-I4/VPro 16-Channel NVR, AcuSeek & AcuSearch, Guanlan AI Analytics, 8-Ch Facial Recognition, H.265+, 32-Ch 1080p Decoding, IP Speaker Support
Model :
SKU : DS-7716NXI-I4/ VPRO
About this item
0Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
The Hikvision DS-7716NXI-I4/VPro 16-Channel Network Video Recorder (NVR) is an intelligent surveillance solution built for advanced security applications in commercial and enterprise environments. As part of the I/VPro Series, it integrates Guanlan AI analytics to deliver powerful smart detection, event classification, and efficient video management.
Featuring AcuSeek and AcuSearch functions, this NVR enables fast and accurate video retrieval, helping users quickly locate specific events within large amounts of recorded footage. It supports up to 8-channel facial recognition, allowing face picture comparison to enhance security monitoring and access management.
With support for H.265+ video compression, the system reduces bandwidth and storage consumption while maintaining high video quality. The NVR supports up to 16 IP camera inputs and provides up to 32-channel 1080p decoding capability, ensuring smooth live view and playback performance.
Additionally, IP speaker support enables integration of audio alerts and voice broadcasting, creating a more proactive and responsive surveillance system. The DS-7716NXI-I4/VPro is ideal for offices, retail stores, industrial facilities, and enterprise security setups requiring AI-powered performance.
Key Features
16-channel IP Network Video Recorder (NVR)
AcuSeek & AcuSearch for intelligent video search
Guanlan AI analytics for advanced event detection
Up to 8-channel facial recognition support
H.265+ compression for optimized storage efficiency
Up to 32-channel 1080p decoding capability
IP speaker support for audio alerts
Suitable for commercial and enterprise surveillance
Model: DS-7716NXI-I4/VPro
Specification
16-Channel AI Network Video Recorder (1.5U) – Technical Specifications
Intelligent Analytics
| AI by NVR | Facial recognition |
| AI by NVR & Camera | Facial recognition, perimeter protection, video structuralization, AcuSearch, motion detection 2.0, ANPR, people counting, AcuSeek |
| AI Engine | Dual engine (1 for Face Picture & AcuSearch, 1 for AcuSeek) |
Facial Recognition
| Face Picture Library | Up to 16 libraries, up to 50,000 face pictures total (≤512 KB each, ≤1 GB total) |
| Face Picture Comparison | 8 Channels |
| Facial Detection & Analytics | Face comparison, human face capture, face picture search |
| Performance | 4-ch face capture (4×2MP / 2×4MP / 1×8MP, H.264/H.265) |
AcuSearch & AcuSeek
| Performance | Up to 300,000 targets/day (with Hikvision AcuSense cameras enabled) |
| Search Language | English |
ANPR (By Camera)
| Supported Channels | All Channels |
| Vehicle Attributes | Plate number, license plate color, license plate type |
| Vehicle Details | Vehicle brand, vehicle color, vehicle type |
| Supported Regions | Asia-Pacific, Europe, Middle East, Africa, North & South America (extensive country coverage) |
Video & Audio
| IP Video Input | 16 Channels |
| Incoming Bandwidth | 192 Mbps |
| Outgoing Bandwidth | 256 Mbps |
| HDMI Output | HDMI1: Up to 4K (3840×2160) @30Hz HDMI2: Up to 1080p @60Hz |
| VGA Output | Up to 1080p @60Hz |
| Video Output Mode | HDMI/VGA independent output |
| Audio Output | 1-ch RCA (Linear, 1 KΩ) |
| Two-Way Audio | 1-ch RCA (2.0 Vp-p, 1 KΩ) |
| Decoding Format | H.265+, H.265, H.264+, H.264 |
| Recording Resolution | Up to 32MP (32MP/24MP/12MP/8MP/6MP/5MP/4MP/3MP/1080p/720p/VGA etc.) *Supports up to 4-ch 32MP/24MP IP inputs |
| Synchronous Playback | 16 Channels |
| Live View Division | 1/2/4/6/8/9/16 |
| Decoding Capability | AI Enabled: 20-ch @1080p (30fps) AI Disabled: 32-ch @1080p (30fps) |
| Audio Compression | G.711u, G.711a, G.722, G.726, AAC, MP2L2, PCM |
| Dual-Stream Recording | Supported |
| Stream Type | Video / Video & Audio |
Network
| Network Interface | 2 × RJ-45 10/100/1000 Mbps |
| Remote Connection | Up to 128 Users |
| Protocols | TCP/IP, DHCP, IPv4/IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS, ONVIF 2.2, OTAP |
| API | ONVIF (Profile S/G), SDK, ISAPI |
| Camera Access | ONVIF 2.5, RTSP |
Storage & Interfaces
| SATA | 4 Interfaces (Up to 20TB per HDD) |
| Alarm In/Out | 16 / 9 |
| USB | Front: 2 × USB 2.0 Rear: 1 × USB 3.0 |
General
| Chassis | 1.5U |
| Power Supply | 100–240 VAC, 50–60 Hz |
| Power Consumption | ≤ 50W (without HDD) |
| Operating Temperature | -10°C to 55°C |
| Operating Humidity | 10% to 90% |
| Dimensions | 440 × 391 × 72 mm (17.32" × 15.39" × 2.81") |
| Weight | ≤ 5 kg (without HDD) |
| Certifications | CE, CB, REACH, WEEE, UKCA, RCM, IC, LOA, KC |
