MSI MAG X870 TOMAHAWK WIFI ATX AM5 Motherboard, Supports AMD Ryzen 9000/8000/7000, DDR5 8400+ (OC), USB4, Wi-Fi 7 | 911-7E51-001
Model :
SKU : MB-MSI MAG X870 TOMAHA WI
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
About this item
Description
Unleash Next-Gen Performance: MSI MAG X870 TOMAHAWK WIFI
The MAG series is legendary for its balance of durability and performance. The X870 TOMAHAWK WIFI carries this legacy forward, providing the Ultra Performance power delivery and advanced thermal solutions needed to push your Ryzen CPU to its absolute limits.
Ultra Performance Power Design: To handle the power requirements of multi-core flagship CPUs, this board features a 14+2+1 Duet Rail Power System. Built on an 8-layer server-grade PCB with thickened copper, it ensures stable power delivery even under extreme gaming or rendering loads. Core Boost and Memory Boost technologies further optimize the signal paths for maximum efficiency.
Advanced Frozr Guard Cooling: Stay cool under pressure. The TOMAHAWK is equipped with an Extended Heatsink and high-quality 7W/mK MOSFET thermal pads. The EZ M.2 Shield Frozr II protects your high-speed SSDs from thermal throttling, ensuring non-stop performance during long gaming sessions or heavy file transfers.
Lightning-Fast Connectivity and Gaming:
- PCIe 5.0 Support: Get ready for next-gen graphics cards and storage with Lightning Gen 5 slots, offering double the bandwidth of the previous generation
- USB4 40Gbps: Two rear Type-C ports provide massive bandwidth for external drives and professional peripherals.
- Next-Gen Networking: Experience the future with Wi-Fi 7 (up to 5.8Gbps) and 5G LAN, providing lower latency and higher stability for online competitive gaming.
EZ DIY Solutions: Building a PC has never been easier. MSI’s EZ DIY features include the EZ PCIe Release for quick GPU swaps, EZ M.2 Clips for tool-less SSD installation, and a pre-installed EZ Antenna for a seamless setup experience.
Specification
| Chipset | AMD X870 |
| CPU Support | AMD Ryzenâ„¢ 9000 / 8000 / 7000 Series Desktop Processors |
| CPU Socket | AM5 |
| Memory Slots | 4x DDR5 UDIMM |
| Maximum Memory | Up to 256GB |
| Memory Speed | DDR5 8400 – 5600 MT/s (OC) DDR5 5600 – 4800 MT/s (JEDEC) |
| Memory Features | Dual-Channel Mode AMD EXPOâ„¢ Support Memory Overclocking Support Non-ECC, Un-buffered Supports CUDIMM (Clock Driver bypass mode only) |
| Onboard Graphics Output | 1x HDMIâ„¢ 2.1 FRL (Up to 8K @ 60Hz)* 2x USB Type-C DisplayPort (DP 1.4, Up to 4K @ 60Hz)* |
| Expansion Slots | 3x PCIe x16 Slots PCI_E1: PCIe 5.0 x16 (CPU) PCI_E2: PCIe 3.0 x1 (Chipset) PCI_E3: PCIe 4.0 x4 (Chipset) |
| Audio | Realtek® ALC4080 Codec 7.1-Channel USB High Performance Audio Up to 32-bit / 384kHz Playback S/PDIF Output Supported |
| Storage | 4x M.2 Slots M.2_1: PCIe 5.0 x4 (CPU) M.2_2: PCIe 5.0 x4 (CPU) M.2_3: PCIe 4.0 x2 (Chipset) M.2_4: PCIe 4.0 x4 (Chipset) 4x SATA 6Gb/s |
| RAID Support | RAID 0 / 1 / 5 / 10 (M.2 NVMe) *RAID 5 supported by Ryzenâ„¢ 9000 Series only |
| Multi-GPU Support | AMD Multi-GPU |
| USB Ports | Rear: 4x USB 2.0, 3x USB 5Gbps Type-A, 2x USB 10Gbps Type-A, 1x USB 10Gbps Type-C, 2x USB 40Gbps Type-C Front: 4x USB 2.0, 4x USB 5Gbps Type-A, 1x USB 20Gbps Type-C |
| LAN | Realtek® 8126-CG 5G LAN |
| Wireless Connectivity | Wi-Fi 7 (802.11 a/b/g/n/ac/ax/be) Tri-Band 2.4GHz / 5GHz / 6GHz Bluetooth® 5.4 |
| Internal Connectors | ATX Power Connector 2x CPU Power Connectors PCIe 8-pin Power Connector 1x CPU Fan, 1x Pump/System Fan, 6x System Fans RGB: 3x ARGB Gen2, 1x RGB TPM 2.0 Header |
| Debug & LEDs | 4x EZ Debug LED, 1x EZ Digit Debug LED |
| Back Panel I/O | Clear CMOS Button Flash BIOS Button HDMIâ„¢ USB 40Gbps Type-C USB 10Gbps Type-C & Type-A USB 5Gbps Type-A USB 2.0 5G LAN Wi-Fi / Bluetooth Antenna Audio Jacks |
| Operating System | Windows® 11 64-bit |
