Home/Networking/Accessories/Network Accessories/TP-Link ER7206 Omada Gigabit VPN Gateway, SPI Fire...
TP-Link ER7206 Omada Gigabit VPN Gateway, SPI Firewall Omada SDN Integrated Load Balance Lightning Protection, Rack Mount/Desktop/Wall Mount
Model :
SKU : NS-TPLINK ER7206 VPN GATE
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
TP-Link ER7206 Omada Gigabit VPN Gateway, SPI Firewall Omada SDN Integrated Load Balance Lightning Protection, Rack Mount/Desktop/Wall Mount Specifications
| Access Control | Source/Destination IP Based Access Control |
| Filtering | WEB Group Filtering, URL Filtering, Web Security |
| ARP Inspection | Sending GARP Packets, ARP Scanning, IP-MAC Binding |
| Attack Defense | TCP/UDP/ICMP Flood Defense, Block TCP Scan, Block Ping from WAN |
| Standards and Protocols | IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1q, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP |
| Interface | 1x Gigabit SFP WAN/LAN, 1x Gigabit WAN, 4x Gigabit LAN/WAN, 1x USB 3.0 |
| Network Media | 10/100/1000BASE-T: UTP Cat 3~6 up to 100m, STP 100?? |
| Fan Quantity | Fanless |
| Button | Reset Button |
| Power Supply | 12V DC / 1A |
| PoE Budget | Not Applicable |
| Flash | 128 MB NAND |
| DRAM | 512 MB DDR4 |
| LED | PWR, SYS, SFP, USB, WAN, LAN |
| Dimensions (W x D x H) | 226 x 131 x 35 mm |
| Protection | 4 kV surge protection |
| Enclosure | Steel |
| Mounting | Desktop, Wall-Mounting, Rack-Mounting |
| Max. Power Consumption | 7.5 W (with USB), 4.5 W (without USB) |
| IPS Throughput | TCP: 229 Mbps, UDP: 188 Mbps |
| DPI Throughput | TCP: 933 Mbps, UDP: 927 Mbps |
| WireGuard VPN | 341.3 Mbps |
| Concurrent Sessions | 150,000 |
| New Sessions/Second | 5,300 |
| NAT Throughput | Static IP: 945.3 / 940.5 Mbps, DHCP: 939.6 / 940.9 Mbps, PPPoE: 943.6 / 940.9 Mbps, L2TP: 880.1 / 859.0 Mbps, PPTP: 855.0 / 907.2 Mbps |
| IPsec VPN Throughput | Up to 617.1 Mbps (AES256) |
| OpenVPN | 139.1 Mbps |
| L2TP VPN Throughput | Unencrypted: 977.4 Mbps, Encrypted: 334.6 Mbps |
| PPTP VPN Throughput | Unencrypted: 1064.1 Mbps, Encrypted: 206.8 Mbps |
| SSL VPN Throughput | 131.6 Mbps |
| Packet Forwarding Rate | 66-byte: 1,453,489 pps, 1518-byte: 81,279 pps |
| WAN Connection Types | Static IP, Dynamic IP, PPPoE, PPTP, L2TP |
| MAC Clone | Yes |
| DHCP | DHCP Server, DHCPv6 PD, Options Customization, Address Reservation, Multi-IP, Multi-Net |
| IPv6 | StaticIP, SLAAC, DHCPv6, PPPoE, 6to4 Tunnel, PassThrough, Non-Address mode |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| Access Control (Advanced) | IP/Port/Protocol/Domain Name Filtering |
| Advanced Routing | Static Routing, Policy Routing, RIP, OSPF |
| Bandwidth Control | IP-based |
| Load Balance | Intelligent Balance, Optimized Routing, Link Backup, Online Detection |
| NAT | 1-to-1 NAT, Multi-Net NAT, Port Forwarding/Triggering, NAT-DMZ, ALG, UPnP |
| Session Limit | IP-based |
| VPN Protocols | GRE (Standalone), SD-WAN (Controller), SSL VPN (50), IPsec VPN (100), PPTP (50), L2TP (50), OpenVPN (55), WireGuard (20) |
| Authentication | No Auth, Simple Password, Hotspot, Radius, LDAP, External Portal |
| Omada App | Yes (Omada Controller Required) |
| Centralized Management | Omada Cloud-Based, Hardware, Software Controller |
| Cloud Access | Yes |
| Dynamic DNS | Dyndns, No-IP, Peanuthull, Comexe, Custom |
| Maintenance | Web UI, Remote Mgmt, SNMP, CLI, Syslog, Port Mirroring, NTP, Diagnostics |
| Zero-Touch Provisioning | Yes |
| Management Tools | Auto Discovery, Batch Config, Firmware Upgrade, Network Monitoring, Event Warnings, Unified Config, Reboot Schedule |
| Certification | CE, FCC, RoHS |
| Package Contents | ER7206, Power Adapter, Quick Guide, Rackmount Kit |
| System Requirements | Windows 98SE~10, macOS, NetWare, UNIX, Linux |
| Operating Temperature | 0??C to 40??C |
| Storage Temperature | -40??C to 70??C |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 5% to 90% non-condensing |
