TP-Link Omada Beam Bridge 5 UR KIT, 5GHz 867Mbps Ultra-Range Indoor/Outdoor Wireless Bridge, 15km Range | Beam Bridge 5 UR KIT

The TP-Link Omada Beam Bridge 5 UR KIT (1210002603782) is the flagship of the Omada wireless bridge lineup, specifically engineered for Ultra-Range (UR) deployments. While standard bridges are limited to 1km or 5km, the Beam Bridge 5 UR extends your network reach to a massive 15 kilometers. This makes it an ideal alternative to expensive fiber-optic trenching for connecting remote mining sites, agricultural hubs, or providing internet to island communities. Pre-configured for immediate auto-pairing, this kit delivers enterprise-level power with consumer-level ease of setup.

Key Features
15km (9.3 mi) Ultra-Long Range: Featuring massive 23dBi high-gain directional antennas, this kit focuses its signal into a narrow, high-intensity beam (9° Horizontal / 7° Vertical), ensuring a reliable connection across vast distances that would stall lesser hardware.

High-Speed 867 Mbps Throughput: Built on the 802.11ac standard with 2×2 MIMO technology, the kit handles high-bandwidth tasks like 4K video surveillance feeds and large database synchronizations without latency issues.

Effortless Plug-and-Play Setup: The Main AP and Client AP are pre-paired out of the box. Simply mount them, power them on, and they will establish a secure Point-to-Point (PtP) link automatically.

App-Guided Alignment: Long-distance alignment is made easy with the Omada app’s visual signal strength tool. This ensures you find the perfect "sweet spot" for maximum speed over several kilometers.

Flexible PoE Deployment: The Gigabit PoE port supports both 802.3af PoE and Passive PoE, allowing you to power the units through a single Ethernet cable from a switch or the included passive adapter.

Industrial Outdoor Durability: Rated IP65 for dust and water resistance, with a wide operating temperature range of -40°C to 70°C. It also features 6kV lightning protection and high ESD resistance to survive the most extreme weather conditions.

Advanced Management & Intelligence
The Beam Bridge 5 UR KIT supports Omada SDN, providing a single, centralized interface to manage your entire network. You can monitor link status, test speeds, and troubleshoot connections remotely via the cloud. For more localized setups, it also supports a standalone mode with a user-friendly web GUI, giving you total control over channel selection and power output.

Why This Bridge Kit Stands Out
The Beam Bridge 5 UR KIT stands out as the most powerful PtP solution in the Omada ecosystem. By combining the ultra-high 23dBi gain with the 867 Mbps speed of AC-class wireless, it offers a performance profile usually reserved for much more expensive industrial radio systems. It is the ultimate tool for professional installers in the UAE who need to bridge massive gaps with absolute reliability.
