Flex Bridge 5 Works with Flex & Sector bridges for Point-to-Point/Multipoint Bridging Long-Range 5 GHz 867Mpbs Wireless Bridging up to 3.1 miles Powering Surveillance with 2 x PoE Out Ports Role & DIP Switches for Simple Pairing Easy Alignment with Ball-Joint & Versatile Installation Industry-Leading IP66 Weatherproof Flexible Power Supply Options App-Guided Alignment for Optimal Performance Remote Monitoring with Standalone & SDN Management
The TP-Link Omada Flex Bridge 5 is a versatile and durable wireless bridge designed to extend enterprise networks across massive outdoor spaces. Whether you need to link multiple buildings, remote workshops, or expansive surveillance grids, this high-gain 5 GHz bridge acts as an invisible Ethernet cable, eliminating the staggering costs of trenching physical lines.
Key Features
5 km Long-Range Connectivity: Integrated dual-polarized 17 dBi directional antennas focus the 5 GHz Wi-Fi signal to maintain a robust, high-bandwidth connection up to 5 kilometers (3.1 miles) away.
Fast 867 Mbps Wireless Speed: Supports the 802.11ac standard to deliver 867 Mbps on the 5 GHz band, providing ample bandwidth for multi-camera 4K security streams and VoIP communications.
2x PoE Out for Surveillance: Features three Gigabit Ethernet ports. The main port supports PoE In, while the two secondary ports provide PoE Out to directly power connected IP cameras or additional access points.
Simple Pairing via DIP Switches: Role switching and pairing code DIP switches allow installers to instantly pair bridges on-site without logging into a web interface, massively reducing deployment complexity.
App-Guided Alignment: The Omada mobile app provides real-time signal strength visualization to help you perfectly align the ball-joint mounting bracket for optimal wireless transmission.
Flexible Power Supply: Operates via standard 802.3at/af PoE, 24V Passive PoE (54V adapter included), or direct 12V DC, making it adaptable to PoE switches or off-grid solar power setups.
Extreme Weatherproof Design: Enclosed in a rugged IP66-rated casing with 6 kV lightning protection, it is guaranteed to withstand harsh sun, torrential rain, dust, and temperature extremes (-40 °C to 70 °C).
Performance & Management The Flex Bridge 5 integrates seamlessly into the Omada Software Defined Networking (SDN) ecosystem. IT administrators can centrally manage, monitor, and configure the bridge alongside all other Omada routers, switches, and APs from a single cloud dashboard.
Why This Product Stands Out The TP-Link Flex Bridge 5 stands out by combining an ultra-long 5 km range with built-in PoE passthrough, allowing you to bridge a network and power two IP security cameras from a single device mounted on a remote pole.
Ethernet Ports: 3× 10/100/1000 Mbps Gigabit RJ45 Ports (2× Ports support PoE Out / Passthrough)
Hardware DIP Switches: Hardware Role Switch (AP / Client) & Pairing Code DIP Switch (for toolless quick pairing)
Physical Controls: Hardware Reset button
Power Architecture & PoE
Flexible Power Inputs:
12V DC input
Standard IEEE 802.3af/at PoE
24V Passive PoE (54V Passive PoE injector included for indoor use)
Power Consumption: 12 W (DC) | 26.06 W (PoE input with maximum PoE Out draw)
Outdoor Durability & Surge Protection
Ingress Protection: IP66-rated weatherproof and dustproof enclosure
Lightning & ESD Immunity:
Air Discharge: ±8 kV
Contact Discharge: ±4 kV
Common Mode (10/700 μs): ±6 kV
Centralized Omada Management
Platform Support: Omada Central (Cloud-based), Omada Hardware Controller, Omada Software Controller, and Omada Mobile App
Deployment & Remote Access: Zero-Touch Provisioning (ZTP), Cloud Web Management, SSH, SNMP, NTP sync, Email Event Alerts, and Remote LED Control
Advanced Networking & Security
802.1Q VLAN Tagging, Rogue AP Detection, Enterprise-grade Wireless Encryption
RADIUS Accounting, Client Rate Limiting, Radio Schedules, Reboot Schedules, and SSID Broadcast control
Dimensions, Mounting & Weight
Dimensions (W × D × H): 214.2 × 50.8 × 119.8 mm (8.4 × 2.0 × 4.7 in)
Weight: 0.59 kg (1.3 lbs)
Mounting: Pole and Wall mounting hardware included
Environmental Operating Range
Operating Temp: -40 °C to 70 °C (-40 °F to 158 °F) | Humidity: 10% to 90% non-condensing Storage Temp: -40 °C to 70 °C (-40 °F to 158 °F) | Humidity: 5% to 90% non-condensing
Certifications & Box Contents
Certifications: CE, FCC, RoHS
Package Contents: Flex Bridge 5 unit, Passive PoE Adapter, AC Power Cord, Pole/Wall Mounting Kit, Installation Guide
Description
The TP-Link Omada Flex Bridge 5 is a versatile and durable wireless bridge designed to extend enterprise networks across massive outdoor spaces. Whether you need to link multiple buildings, remote workshops, or expansive surveillance grids, this high-gain 5 GHz bridge acts as an invisible Ethernet cable, eliminating the staggering costs of trenching physical lines.
Key Features
5 km Long-Range Connectivity: Integrated dual-polarized 17 dBi directional antennas focus the 5 GHz Wi-Fi signal to maintain a robust, high-bandwidth connection up to 5 kilometers (3.1 miles) away.
Fast 867 Mbps Wireless Speed: Supports the 802.11ac standard to deliver 867 Mbps on the 5 GHz band, providing ample bandwidth for multi-camera 4K security streams and VoIP communications.
2x PoE Out for Surveillance: Features three Gigabit Ethernet ports. The main port supports PoE In, while the two secondary ports provide PoE Out to directly power connected IP cameras or additional access points.
Simple Pairing via DIP Switches: Role switching and pairing code DIP switches allow installers to instantly pair bridges on-site without logging into a web interface, massively reducing deployment complexity.
App-Guided Alignment: The Omada mobile app provides real-time signal strength visualization to help you perfectly align the ball-joint mounting bracket for optimal wireless transmission.
Flexible Power Supply: Operates via standard 802.3at/af PoE, 24V Passive PoE (54V adapter included), or direct 12V DC, making it adaptable to PoE switches or off-grid solar power setups.
Extreme Weatherproof Design: Enclosed in a rugged IP66-rated casing with 6 kV lightning protection, it is guaranteed to withstand harsh sun, torrential rain, dust, and temperature extremes (-40 °C to 70 °C).
Performance & Management The Flex Bridge 5 integrates seamlessly into the Omada Software Defined Networking (SDN) ecosystem. IT administrators can centrally manage, monitor, and configure the bridge alongside all other Omada routers, switches, and APs from a single cloud dashboard.
Why This Product Stands Out The TP-Link Flex Bridge 5 stands out by combining an ultra-long 5 km range with built-in PoE passthrough, allowing you to bridge a network and power two IP security cameras from a single device mounted on a remote pole.
Ethernet Ports: 3× 10/100/1000 Mbps Gigabit RJ45 Ports (2× Ports support PoE Out / Passthrough)
Hardware DIP Switches: Hardware Role Switch (AP / Client) & Pairing Code DIP Switch (for toolless quick pairing)
Physical Controls: Hardware Reset button
Power Architecture & PoE
Flexible Power Inputs:
12V DC input
Standard IEEE 802.3af/at PoE
24V Passive PoE (54V Passive PoE injector included for indoor use)
Power Consumption: 12 W (DC) | 26.06 W (PoE input with maximum PoE Out draw)
Outdoor Durability & Surge Protection
Ingress Protection: IP66-rated weatherproof and dustproof enclosure
Lightning & ESD Immunity:
Air Discharge: ±8 kV
Contact Discharge: ±4 kV
Common Mode (10/700 μs): ±6 kV
Centralized Omada Management
Platform Support: Omada Central (Cloud-based), Omada Hardware Controller, Omada Software Controller, and Omada Mobile App
Deployment & Remote Access: Zero-Touch Provisioning (ZTP), Cloud Web Management, SSH, SNMP, NTP sync, Email Event Alerts, and Remote LED Control
Advanced Networking & Security
802.1Q VLAN Tagging, Rogue AP Detection, Enterprise-grade Wireless Encryption
RADIUS Accounting, Client Rate Limiting, Radio Schedules, Reboot Schedules, and SSID Broadcast control
Dimensions, Mounting & Weight
Dimensions (W × D × H): 214.2 × 50.8 × 119.8 mm (8.4 × 2.0 × 4.7 in)
Weight: 0.59 kg (1.3 lbs)
Mounting: Pole and Wall mounting hardware included
Environmental Operating Range
Operating Temp: -40 °C to 70 °C (-40 °F to 158 °F) | Humidity: 10% to 90% non-condensing Storage Temp: -40 °C to 70 °C (-40 °F to 158 °F) | Humidity: 5% to 90% non-condensing
Certifications & Box Contents
Certifications: CE, FCC, RoHS
Package Contents: Flex Bridge 5 unit, Passive PoE Adapter, AC Power Cord, Pole/Wall Mounting Kit, Installation Guide
