Unifi UXG-Max Gateway Max Compact Multi-WAN Independent Gateway, Full 2.5G support, Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server | UXG-Max
Model :
SKU : UNIFI-GATEWAY Max
About this item
Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
Up to 1.5 Gbps routing with IDS/IPS
(1) 2.5 GbE WAN port
USB-C powered (adapter included)
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Unifi UXG-Max Gateway Max Compact Multi-WAN Independent Gateway, Full 2.5G support, Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server | UXG-Max Specifications
| Mechanical | |
|---|---|
| Dimensions | 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2") |
| Weight | 520 g (1.1 lb) |
| Enclosure Material | Polycarbonate |
| Resistance | IK04 |
| Hardware | |
| Processor | Quad-core ARM?? Cortex??-A53 at 1.5 GHz |
| Memory Information | 2 GB DDR4 |
| Management Interface | Ethernet, Bluetooth |
| Networking Interface |
LAN: (4) 2.5 GbE RJ45 ports WAN: (1) 2.5 GbE RJ45 port |
| IDS/IPS Throughput | 1.5 Gbps* *Measured with iPerf3 on DHCP WAN. Performance may be reduced with PPPoE depending on ISP implementation. |
| Power Method | USB type C (5V/3A) |
| Supported Voltage Range | 100???240V |
| Max. Power Consumption | 9.6W |
| LED |
Ethernet: White: link/activity |
| Button | (1) Factory reset |
| Ambient Operating Temperature | -10 to 40?? C (14 to 104?? F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Gateway Features | |
| Performance |
WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Internet quality and outage reporting |
| Next-generation Security |
Application-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall |
| Advanced Networking |
License-free SD-WAN* WireGuard, L2TP, and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport* and Identity Enterprise VPN** Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IPv6 ISP support |
|
*When paired with a CloudKey or Official UniFi Hosting. **When paired with a CloudKey. |
|
| Application Requirements | |
| UniFi Network | Version 8.1.113 and later |
Specification
Unifi UXG-Max Gateway Max Compact Multi-WAN Independent Gateway, Full 2.5G support, Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server | UXG-Max Specifications
| Mechanical | |
|---|---|
| Dimensions | 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2") |
| Weight | 520 g (1.1 lb) |
| Enclosure Material | Polycarbonate |
| Resistance | IK04 |
| Hardware | |
| Processor | Quad-core ARM?? Cortex??-A53 at 1.5 GHz |
| Memory Information | 2 GB DDR4 |
| Management Interface | Ethernet, Bluetooth |
| Networking Interface |
LAN: (4) 2.5 GbE RJ45 ports WAN: (1) 2.5 GbE RJ45 port |
| IDS/IPS Throughput | 1.5 Gbps* *Measured with iPerf3 on DHCP WAN. Performance may be reduced with PPPoE depending on ISP implementation. |
| Power Method | USB type C (5V/3A) |
| Supported Voltage Range | 100???240V |
| Max. Power Consumption | 9.6W |
| LED |
Ethernet: White: link/activity |
| Button | (1) Factory reset |
| Ambient Operating Temperature | -10 to 40?? C (14 to 104?? F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Gateway Features | |
| Performance |
WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Internet quality and outage reporting |
| Next-generation Security |
Application-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall |
| Advanced Networking |
License-free SD-WAN* WireGuard, L2TP, and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport* and Identity Enterprise VPN** Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IPv6 ISP support |
|
*When paired with a CloudKey or Official UniFi Hosting. **When paired with a CloudKey. |
|
| Application Requirements | |
| UniFi Network | Version 8.1.113 and later |
