The Fractal Design Meshify 3 XL (FD-C-MES3X-03) is designed for those who refuse to compromise. Retaining the signature angular mesh front for filtered high-airflow intake, this "XL" variant provides the thermal headroom and physical volume required for flagship hardware. Whether you are building a dual-socket workstation or a liquid-cooled gaming beast, the Meshify 3 XL delivers a refined, industrial aesthetic with the added flair of integrated RGB.
Performance: Ambience Pro and Aspect 14 Cooling
The Meshify 3 XL features the Ambience Pro lighting suite, which adds sophisticated, synchronized illumination to the chassis. To drive airflow, it includes three Aspect 14 RGB fans, known for their high efficiency and low noise. The case is a radiator powerhouse, capable of mounting up to a 480mm or 420mm radiator in the front and top simultaneously, ensuring that even the most heat-intensive CPUs and GPUs remain at optimal temperatures.
Versatility: Dual Layout Design
Adapt your case to your specific needs. The Meshify 3 XL features a dual-layout interior. Use the Open Layout for massive water-cooling reservoirs and extra-long graphics cards, or switch to the Storage Layout to support an incredible number of HDDs for server-grade storage capacity. The chassis supports GPUs up to 549mm (without front fans), making it compatible with every modern graphics card on the market.
Connectivity: Modern Top I/O
The top panel provides instant access to high-speed data. It features a USB 3.2 Gen 2x2 Type-C port (20Gbps), two USB 3.0 ports, and a dedicated RGB controller button. This ensures you can connect high-speed external NVMe drives or charge mobile devices at maximum speeds while managing your lighting effects without opening software.
Why This Case Stands Out
Massive Motherboard Support: Fits everything from Mini-ITX to workstation-grade SSI-EEB boards.
Extensive Radiator Support: Front and Top support up to 480/420mm radiators for extreme loops.
Ambience Pro Lighting: Integrated RGB ecosystem for a premium, unified glow.
Tool-less Panels: Bolt-free tempered glass and push-to-lock panels for effortless access.
| 3.5"/2.5" Drive Mounts | 2 / 4 |
| Dedicated 2.5" Drive Mounts | 1 |
| 5.25" Drive Mounts | None |
| Expansion Slots | 7 |
| Adjust Pro Hub | Included in Ambience Pro RGB version |
| Ambience Case Lighting | Available in Ambience Pro RGB version |
| Ports | 1 x USB Type-C (20 Gbps) 2 x USB Type-A (5 Gbps) 1 x Audio Combo Jack Power Button |
| Total Fan Mounts | 10 x 140 mm / 7 x 120 mm |
| Front Fan Support | 3 x 120/140 mm 2 x 180 mm (3 x 140 mm Momentum fans included) |
| Top Fan Support | 3 x 120/140 mm |
| Rear Fan Support | 1 x 120/140 mm |
| Bottom Fan Support | None |
| Side Fan Support | 3 x 140 mm (No 120 mm support without radiator) |
| Front Radiator | 280 / 360 mm |
| Top Radiator | 360 / 420 mm (Up to 475 mm) |
| Rear Radiator | Up to 120 / 140 mm |
| Side Radiator | 360 mm (with brackets) |
| PSU Max Length | 230 mm |
| GPU Max Length | 512 mm |
| GPU Max Height | 189 mm (7-slot, including cables) |
| CPU Cooler Max Height | 182 mm |
| Cable Routing Space | 37.5 mm |
| Cable Cover | Yes |
| Cable Organizers | 3 Hook-and-loop straps + 3 Cable Aligners |
| Tool-less Push-to-lock | Both Side Panels, Bottom Filter, Front Panel, Top Panel |
| Captive Thumbscrews | Top Radiator Bracket, Air Guide, PSU Bracket |
| Dust Filters | PSU (Bottom) |
| Left Side Panel | Industrial Steel (Solid) / Tempered Glass (TG/RGB/Ambience Pro RGB) |
| Right Side Panel | Industrial Steel |
| Power Supply Type | ATX |
| Motherboard Support | E-ATX (330 mm) ATX mATX ITX EE-ATX SSI-EEB SSI-CEB |
| Case Dimensions (L × W × H) | 575 x 245 x 515 mm |
| Case (Without Feet/Protrusions/Screws) | 565 x 245 x 515 mm |
| Package Dimensions | 596 x 350 x 550 mm |
| Net Weight | 10.5 kg (Solid) 10.9 kg (TG / RGB) 11.4 kg (Ambience Pro RGB) |
| Gross Weight | 12.4 kg (Solid) 13 kg (TG / RGB) 13.3 kg (Ambience Pro RGB) |
