The Fractal Design Meshify 3 XL Black TG (FD-C-MES3X-02) is the ultimate evolution of the Meshify series, scaled to meet the demands of enterprise-level hardware and extreme enthusiasts. Built to handle the massive thermal output of flagship 2026 components, this full tower provides a colossal interior that makes even the largest parts look at home. For users in Abu Dhabi and Dubai requiring a high-performance "command center," the Meshify 3 XL offers an unrivaled mix of clinical thermal efficiency and a premium view of their internal hardware.
Key Features
The standout feature of the Meshify 3 XL is its incredible modularity. Using the Dual-Layout design, you can switch from an "Open Layout" for extreme water cooling to a "Storage Layout" that supports vast arrays of hard drives. The chassis supports massive SSI-EEB and E-ATX motherboards, ensuring compatibility with multi-GPU setups and high-core-count workstation platforms. The light-tinted tempered glass side panel provides a clear yet slightly professional aesthetic, perfect for showcasing high-end components without excessive glare.
Performance / Technology
Performance is driven by the signature Aero-Flow 3D Mesh front panel, which facilitates unrestricted air intake to keep critical components cool under 24/7 heavy loads. The XL frame allows for industry-leading radiator support, including up to 480mm radiators in both the front and top positions simultaneously. To handle modern high-speed data needs, the front I/O features a USB 3.2 Gen 2x2 Type-C port, delivering blistering 20Gbps transfer speeds—essential for external high-resolution media and professional storage arrays.
Design & Ergonomics
Fractal has prioritized the builder's experience with a fully removable top bracket, providing total access for the installation of massive motherboards and cooling loops. The light-tinted tempered glass panel utilizes a tool-less, push-to-lock latching system for a clean, professional exterior. Cable management is handled with surgical precision, featuring a dedicated 35mm routing chamber, integrated cable guides with Velcro straps, and a pre-installed Nexus+ 3 fan hub to manage a full array of PWM fans.
Compatibility / Use Cases
This full tower is the ideal solution for AI development rigs, 3D rendering workstations, and flagship gaming systems. It easily accommodates the largest modern graphics cards (up to 549mm) without compromise. Whether you are building a massive local storage server with 18+ HDDs or an extreme liquid-cooled showcase rig, the Meshify 3 XL provides the structural integrity, thermal headroom, and modern connectivity required for a flagship 2026 experience.
Why This Product Stands Out
The Fractal Design Meshify 3 XL stands out by delivering industrial-grade scale without losing the refined aesthetic for which Fractal is known. While most "XL" cases focus solely on size, the Meshify 3 XL focuses on high-bandwidth airflow and 20Gbps data speeds. Its combination of massive radiator support, E-ATX compatibility, and iconic mesh design makes it one of the most powerful and future-proof full tower investments available today.
| 3.5"/2.5" drive mounts | 2 / 4 |
| Dedicated 2.5" drive mounts | 1 |
| 5.25” drive mounts | - |
| Expansion slots | 7 |
| Adjust Pro Hub | Included in Ambience Pro RGB version |
| Ambience Case Lighting | Ambience Pro RGB version |
| Front interface | 1 x USB Type-C 20 Gbps, 2 x USB Type-A 5 Gbps, 1x Audio Combo Jack, Power button |
| Total fan mounts | 10 (140 mm) / 7 (120 mm) |
| Front fan | 3x 120/140 mm, 2x 180 mm (3 x 140 mm Momentum Included) |
| Top fan | 3x 120/140 mm |
| Rear fan | 1x 120/140 mm |
| Bottom fan | - |
| Side fan | 3x 140 mm (no 120 support without radiator) |
| Dust filters | PSU (Bottom) |
| Cable routing space | 37.5 mm |
| Cable cover | Yes |
| Cable organizers | 3 Hook-and-loop straps + 3 Cable Aligners |
| Tool-less push-to-lock | Both Side Panels, Bottom Filter, Front Panel, Top Panel |
| Captive thumbscrews | Top Radiator Bracket, Air Guide, PSU Bracket |
| Left side panel | Industrial steel (Solid), Tempered Glass (TG/RGB/Ambience Pro RGB) |
| Right side panel | Industrial steel |
| Power supply type | ATX |
| Motherboard compatibility | E-ATX (330 mm) / ATX / mATX / ITX / EE-ATX / SSI-EEB / SSI-CEB |
| PSU max length | 230 mm |
| GPU max length | 512 mm |
| GPU max height | 189 mm (7 slot) including cables |
| CPU cooler max height | 182 mm |
| Front radiator | 280 / 360 mm |
| Top radiator | 360 / 420 mm (up to 475 mm) |
| Rear radiator | Up to 120 / 140 mm |
| Side radiator | 360 mm (with brackets) |
| Case dimensions (LxWxH) | 575 x 245 x 515 mm |
| Case dimensions w/o feet/protrusions/screws | 565 x 245 x 515 mm |
| Package dimensions | 596 x 350 x 550 mm |
| Net weight | 10.5 kg (Solid) / 10.9 kg (TG and RGB) / 11.4 kg (Ambience Pro RGB) |
| Gross weight | 12.4 kg (Solid) / 13 kg (TG and RGB) / 13.3 kg (Ambience Pro RGB) |
| Package contents | Case, Accessory Box, Manual, Red Note |
| Accessory Box content (Solid/TG/RGB) | PSU Screws x4, MB Screws x12, SSD screws M3 x20, Zip tie x5, HDD rubber x8, MB standoff x4, HDD screws x8 |
| Accessory Box content (Ambience Pro RGB) | PSU Screws x4, MB Screws x12, SSD screws M3 x20, Zip tie x5, HDD rubber x8, MB standoff x4, HDD screws x8, 500 mm Fractal Connect Cable x1, Legacy Splitter Cable |
| EAN | Black Solid: 7340172707219 Black TG Light Tint: 7340172707226 Ambience Pro RGB Black TG Light Tint: 7340172707233 Black RGB TG Light Tint: 7340172709527 Ambience Pro RGB White TG Clear Tint: 7340172707240 White RGB TG Clear Tint: 7340172709534 |
| UPC | Black Solid: 843276107215 Black TG Light Tint: 843276107222 Ambience Pro RGB Black TG Light Tint: 843276107239 Black RGB TG Light Tint: 843276109523 Ambience Pro RGB White TG Clear Tint: 843276107246 White RGB TG Clear Tint: 843276109530 |
| Product Code | Black Solid: FD-C-MES3X-01 Black TG Light Tint: FD-C-MES3X-02 Ambience Pro RGB Black TG Light Tint: FD-C-MES3X-03 Black RGB TG Light Tint: FD-C-MES3X-04 Ambience Pro RGB White TG Clear Tint: FD-C-MES3X-05 White RGB TG Clear Tint: FD-C-MES3X-06 |
| Warranty | 2 Years |
