Fractal Meshify 3 XL Black RGB TG Light Tint Computer Case, Includes 3x Fans, Supports Motherboard up to EE-ATX / SSI-EEB / SSI-CEB, Radiator 360/420mm, 20 Gbps USB Type-C, 2x USB-A | FD-C-MES3X-04

Model : Fractal Design Meshify 3 XL

SKU : ATX-FRACT MESHIF 3XL B RG

About this item

The Fractal Design Meshify 3 XL RGB is a titan of airflow and modularity, designed to house the most ambitious high-end builds of 2026. Featuring an iconic 3D angular mesh front and a light-tinted tempered glass side panel, it combines massive internal volume with vibrant ARGB lighting. With its ability to accommodate dual-processor motherboards and extensive liquid cooling arrays, the Meshify 3 XL is the definitive choice for extreme gaming rigs and professional-grade workstations.

About this item

Description

The Fractal Design Meshify 3 XL RGB (FD-C-MES3X-04) is the ultimate evolution of the Meshify series, scaled to meet the demands of enterprise-level hardware and extreme enthusiasts. Built to handle the massive thermal output of flagship 2026 components, this full tower provides a colossal interior that makes even the largest parts look at home. For users in Abu Dhabi and Dubai requiring a high-performance "command center," the Meshify 3 XL RGB offers an unrivaled mix of clinical thermal efficiency and a sophisticated, synchronized light show.



Key Features
The standout feature of the Meshify 3 XL is its incredible modularity. Using the Dual-Layout design, you can switch from an "Open Layout" for extreme water cooling to a "Storage Layout" that supports vast arrays of hard drives. This RGB edition comes pre-installed with four Aspect 14 RGB PWM fans, providing elite-tier airflow and out-of-the-box lighting synchronization. The chassis supports massive SSI-EEB and E-ATX motherboards, ensuring compatibility with multi-GPU setups and high-core-count workstation platforms.

Performance / Technology
Performance is driven by the signature Aero-Flow 3D Mesh front panel, which facilitates unrestricted air intake to keep critical components cool under 24/7 heavy loads. The XL frame allows for industry-leading radiator support, including up to 480mm radiators in both the front and top positions simultaneously. To handle modern high-speed data needs, the front I/O features a USB 3.2 Gen 2x2 Type-C port, delivering blistering 20Gbps transfer speeds for external high-resolution media and professional storage arrays.

Design & Ergonomics
Fractal has prioritized the builder's experience with a fully removable top bracket, providing total access for the installation of massive motherboards and cooling loops. The light-tinted tempered glass panel utilizes a tool-less, push-to-lock latching system for a clean, professional exterior. Cable management is handled with surgical precision, featuring a dedicated 35mm routing chamber, integrated cable guides with Velcro straps, and a pre-installed Nexus+ 3 fan hub to manage the massive array of fans and RGB lighting.

Compatibility / Use Cases
This full tower is the ideal solution for AI development rigs, 3D rendering workstations, and flagship gaming systems. It easily accommodates the largest modern graphics cards (up to 549mm) without compromise. Whether you are building a massive local storage server with 18+ HDDs or an extreme liquid-cooled showcase rig, the Meshify 3 XL RGB provides the structural integrity, thermal headroom, and modern connectivity required for a flagship 2026 experience.



Why This Product Stands Out
The Fractal Design Meshify 3 XL RGB stands out by delivering industrial-grade scale without losing the refined aesthetic for which Fractal is known. While most "XL" cases focus solely on size, the Meshify 3 XL focuses on high-bandwidth airflow and 20Gbps data speeds. Its combination of massive radiator support, E-ATX compatibility, and iconic mesh design makes it one of the most powerful and future-proof full tower investments available today.

Specification

Fractal Meshify 3 XL Computer Case, Includes 3x Fans, Supports Motherboard up to EE-ATX / SSI-EEB / SSI-CEB, Radiator 360/420mm, 20 Gbps USB Type-C, 2x USB-A Specifications

3.5"/2.5" drive mounts2 / 4
Dedicated 2.5" drive mounts1
5.25” drive mounts-
Expansion slots7
Adjust Pro HubIncluded in Ambience Pro RGB version
Ambience Case LightingAmbience Pro RGB version
Front interface1 x USB Type-C 20 Gbps, 2 x USB Type-A 5 Gbps, 1x Audio Combo Jack, Power button
Total fan mounts10 (140 mm) / 7 (120 mm)
Front fan3x 120/140 mm, 2x 180 mm (3 x 140 mm Momentum Included)
Top fan3x 120/140 mm
Rear fan1x 120/140 mm
Bottom fan-
Side fan3x 140 mm (no 120 support without radiator)
Dust filtersPSU (Bottom)
Cable routing space37.5 mm
Cable coverYes
Cable organizers3 Hook-and-loop straps + 3 Cable Aligners
Tool-less push-to-lockBoth Side Panels, Bottom Filter, Front Panel, Top Panel
Captive thumbscrewsTop Radiator Bracket, Air Guide, PSU Bracket
Left side panelIndustrial steel (Solid), Tempered Glass (TG/RGB/Ambience Pro RGB)
Right side panelIndustrial steel
Power supply typeATX
Motherboard compatibilityE-ATX (330 mm) / ATX / mATX / ITX / EE-ATX / SSI-EEB / SSI-CEB
PSU max length230 mm
GPU max length512 mm
GPU max height189 mm (7 slot) including cables
CPU cooler max height182 mm
Front radiator280 / 360 mm
Top radiator360 / 420 mm (up to 475 mm)
Rear radiatorUp to 120 / 140 mm
Side radiator360 mm (with brackets)
Case dimensions (LxWxH)575 x 245 x 515 mm
Case dimensions w/o feet/protrusions/screws565 x 245 x 515 mm
Package dimensions596 x 350 x 550 mm
Net weight10.5 kg (Solid) / 10.9 kg (TG and RGB) / 11.4 kg (Ambience Pro RGB)
Gross weight12.4 kg (Solid) / 13 kg (TG and RGB) / 13.3 kg (Ambience Pro RGB)
Package contentsCase, Accessory Box, Manual, Red Note
Accessory Box content (Solid/TG/RGB)PSU Screws x4, MB Screws x12, SSD screws M3 x20, Zip tie x5, HDD rubber x8, MB standoff x4, HDD screws x8
Accessory Box content (Ambience Pro RGB)PSU Screws x4, MB Screws x12, SSD screws M3 x20, Zip tie x5, HDD rubber x8, MB standoff x4, HDD screws x8, 500 mm Fractal Connect Cable x1, Legacy Splitter Cable
EANBlack Solid: 7340172707219
Black TG Light Tint: 7340172707226
Ambience Pro RGB Black TG Light Tint: 7340172707233
Black RGB TG Light Tint: 7340172709527
Ambience Pro RGB White TG Clear Tint: 7340172707240
White RGB TG Clear Tint: 7340172709534
UPCBlack Solid: 843276107215
Black TG Light Tint: 843276107222
Ambience Pro RGB Black TG Light Tint: 843276107239
Black RGB TG Light Tint: 843276109523
Ambience Pro RGB White TG Clear Tint: 843276107246
White RGB TG Clear Tint: 843276109530
Product CodeBlack Solid: FD-C-MES3X-01
Black TG Light Tint: FD-C-MES3X-02
Ambience Pro RGB Black TG Light Tint: FD-C-MES3X-03
Black RGB TG Light Tint: FD-C-MES3X-04
Ambience Pro RGB White TG Clear Tint: FD-C-MES3X-05
White RGB TG Clear Tint: FD-C-MES3X-06
Warranty2 Years
