| Operation System | Linux |
| ROM | 32 MB |
| RAM | 128 MB |
| Processor | Embedded high-performance processor |
| Screen Size | 7-inch |
| Operation Method | Capacitive touch screen |
| Type | Colorful TFT |
| Resolution | 1024 ?? 600 |
| Lens | / |
| Resolution | / |
| FOV | / |
| Wide Dynamic Range (WDR) | / |
| Video Compression Standard | / |
| Focal Length | / |
| Audio Input | 1 built-in omnidirectional microphone |
| Audio Compression Standard | G.711U/G.711A |
| Audio Output | 1 built-in loudspeaker |
| Audio Compression Bitrate | 64 Kbps |
| Audio Quality | Noise suppression and echo cancellation |
| Volume Adjustment | Adjustable |
| Message Capacity | TF card inserted: 200 captured pictures, 200 alarm records Without TF card: 2 MB RAM for picture storage; The storage number is decided by the picture size, 200 alarm records |
| Notice Capacity | 200 |
| Linked Indoor Extensions Capacity | 16 |
| Linked Doorphone Capacity | 17 |
| Linked Network Camera Capacity | 16 |
| Network Protocol | TCP/IP, SIP, RTSP |
| Wi-Fi | 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n |
| Bluetooth | / |
| 3G/4G | / |
| Zigbee | / |
| Alarm Input | 8 |
| Network Interface | 1 RJ-45 10/100 Mbps self-adaptive |
| TAMPER | / |
| RS-485 | 1 RS-485 (Half duplex) |
| USB | / |
| TF Card | Support TF card, up to 128 G |
| Alarm Output | 2 |
| Lock Control | 2 relays, Max. 30 VDC 0.3 A |
| Button | / |
| Installation | Surface mounting |
| Indicator | / |
| Weight | Net weight: 355 g (0.8 lb) Gross weight: 683 g (1.5 lb) |
| Protective Level | / |
| Working Temperature | -10 ??C to 55 ??C (14 ??F to 131 ??F) |
| Working Humidity | 10% to 90% (no-condensing) |
| Dimension (W ?? H ?? D) | 200 mm ?? 140 mm ?? 15.1 mm (7.9" ?? 5.5" ?? 0.6") |
| Battery | / |
| Application Environment | Indoor |
| Power Consumption | ??? 5 W |
| Language | English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese (Brazil), Spanish, Hebrew, Romanian, Turkish, Estonian, Danish, Swedish, Norwegian, Finnish, Vietnamese, Croatian, Slovenian, Serbian, Arabic, Portuguese (Portugal), Lithuanian, Uzbek, Kazakh, Mongolian, Ukrainian |
