Hikvision DS-7208HGHI-M1 8-ch 720p 1U H.265 DVR, Human & vehicle targets classification of Motion Detection 2.0

Model :

SKU : DS-7208HGHI-M1 8CH

About this item

0

Inclusive of VAT

Delivery to

FREE scheduled delivery as soon as Loading...

Sold and shipped by: Adarc computers

AED 0.00

stock : 1

About this item

Description

Specification

Hikvision DS-7208HGHI-M1 8-ch 720p 1U H.265 DVR, Human & vehicle targets classification of Motion Detection 2.0 Specification

Motion Detection 2.0	Deep learning-based motion detection 2.0 enabled by default for all analog channels, classifies human and vehicle, reduces false alarms caused by objects like leaves and lights; quick search by object or event type supported
IP Video Input	2-ch (up to 10-ch), up to 5 MP resolution, supports H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input	8-ch, BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron connection
HDTVI Input	1080p25, 1080p30, 720p25, 720p30
AHD Input	1080p25, 1080p30, 720p25, 720p30
HDCVI Input	1080p25, 1080p30, 720p25, 720p30
CVBS Input	Support
HDMI Output	1-ch, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz
VGA Output	1-ch, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz
Video Output Mode	HDMI/VGA simultaneous output
Audio Input	1-ch RCA (2.0 Vp-p, 1 KΩ), 8-ch via coaxial cable
Audio Output	1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio	Reuse the first audio input
Synchronous Playback	8-ch
Video Compression	H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution	For 1080p stream: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF For 720p stream: 720p/WD1/4CIF/VGA/CIF For SD stream: WD1/4CIF/VGA/CIF
Frame Rate	Main stream: - 1080p: 15 fps - 720p: 15 fps - SD: 25 fps (P)/30 fps (N) Sub-stream: - 1080p/720p: CIF/QVGA@15 fps - SD: CIF/QVGA@25 fps (P)/30 fps (N)
Video Bitrate	32 Kbps to 4 Mbps
Stream Type	Video, Video & Audio
Audio Compression	G.711u
Audio Bitrate	64 Kbps
Remote Connection	64
Network Protocol	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS
Total Bandwidth	72 Mbps
Network Interface	1 × RJ45 10/100 Mbps self-adaptive Ethernet interface
SATA	1 × SATA interface, up to 4 TB per disk
USB Interface	Rear panel: 2 × USB 2.0
Alarm In/Out	N/A
Power Supply	12 VDC, 1.5 A
Power Consumption	≤ 17 W (without HDD)
Working Temperature	-10 °C to 55 °C (14 °F to +131 °F)
Working Humidity	10% to 90%
Dimensions	260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
Weight	≤ 1 kg (without HDD, 2.2 lb.)
