Hikvision DS-KAS541 Face Recognition Terminal Kit, 4.3-inch LCD touch screen, Touch-free single-door access control solution, 2 mega pixel dual-lens camera, Deep learning face recognition, Access control with multiple authentication modes

Face Recognition Terminal/System Parameters

Model	DS-K1T341CMF
Operating system	Linux

Face Recognition Terminal/Display Parameters

Screen size	4.3-inch
Operation method	Capacitive touch screen
Type	LCD
Resolution	480 ?? 800

Face Recognition Terminal/Video Parameters

Lens	?? 2
Resolution	2 MP

Face Recognition Terminal/Network

Wired network

10 M/100 M/1000 M self-adaptive

Face Recognition Terminal/Interface

Network interface	1
Lock control	1
Exit button	1
Door contact input	1
TAMPER	1
RS-485	1
Wiegand	1
USB	1

Face Recognition Terminal/Capacity

Face capacity	1,500
Fingerprint capacity	1,500
Card capacity	1,500
Event capacity	150,000

Face Recognition Terminal/Authentication

Face recognition distance	0.3 to 1.5 m
Face recognition accuracy rate	>99%
Face recognition duration	< 0.2 s
Fingerprint recognition duration	< 1 s
Card type	M1 card
Card reading frequency	13.56MHz
Card reading distance	0 to 3 cm
Card reading duration	< 1 s

Face Recognition Terminal/Function

QR code recognition	Support
Face anti-spoofing	Support
Audio prompt	Support
Time synchronization	Support

Face Recognition Terminal/General

Button	Touch screen
Power supply	12 VDC, 2 A
Working temperature	-30 ??C to 60 ??C (-22 ??F to 140 ??F)
Working humidity	0 to 90% (No condensing)
Protective level	IP65
Dimensions	172.5 mm ?? 83.2 mm ?? 22.7 mm (6.79" ?? 3.27" ?? 0.89")
Installation	Surface mounting

Magnetic Lock/General

Model	DS-K4H258S
Unlock method	Current interruption
Maximum holding force	280 kg (617.4 Lbs) linear thrust
Power supply	12 VDC, 340 mA
Indicator	Green (work status)
Surface temperature	??? ambient temperature 20 ??C (68 ??F)
Working temperature	-10 ??C to 55 ??C (14 ??F to 131 ??F)
Working humidity	0 to 95% (relative humidity)
Dimensions	Lock body: 238 mm ?? 45 mm ?? 25 mm (9.4" ?? 1.8" ?? 1.0") Armature plate: 182 mm ?? 38 mm ?? 12.5 mm (7.2 ?? 1.5" ?? 0.5")
Weight	2.1 kg (4.6 Lbs)
Suitable door	Wooden door, glass door, metal door, fireproof door
Shell performance	Hard anodizing electroplating operated
Lock body	Eco-friendly Nickel electroplating operated
Armature plate	Eco-friendly Nickel electroplating operated

Card/General

Model	FM11RF08-M1
RAM	1 K byte
Card reading frequency	13.56 MHz
Card property	Thin card
Function	Read/write
Card reading distance	???10 cm
Working temperature	-20 ??C to 75 ??C (-4 ??F to 167 ??F)
Dimensions	85.5 mm ?? 54 mm ?? 0.8 mm (3.37"?? 2.13" ?? 0.03")
Weight	< 5.6 g (0.2 oz)
Material	PVC
Color	White

Bracket of Magnetic Lock/General

Model	DS-K4H258-LZ
Dimensions (L-bracket)	238 mm ?? 30 mm ?? 47 mm (9.4" ?? 1.2" ?? 1.9")
Dimensions (Z-bracket)	185 mm ?? 44 mm ?? 100 mm (7.3 ?? 1.7" ?? 3.9")
Suitable Door	Wooden, metal
Shell performance	Hard anodizing electroplated
Weight	0.77 kg (1.7 lb)

Exit Button/General

Model	DS-K7P03
Power supply	12 VDC, 40 mA (standby)/70 mA (working)
Current rating	1 A@30 VDC
Working temperature	-20 ??C to 50 ??C (-4 ??F to 122 ??F)
Working humidity	0 to 95% (relative humidity)
Dimensions	86 mm ?? 86 mm ?? 25.7 mm (3.39" ?? 3.39" ?? 1.01")
Weight	0.2 kg (0.44 lb)
Material	Stainless steel
Output contact	NO/NC/COM contact
Aging test	Already passed 1 million times aging test
Suitable door	All kinds of narrow doorframes
