Hikvision DS-7604NXI-K1/4P 4-ch PoE 1U K Series AcuSense 4K NVR, 4-ch IP camera inputs, 40 Mbps incoming bandwidth, Smart Function, Professional and Reliability, HD Video Output, Network & Ethernet Access
Model :
SKU : DS-7604NXI-K1 NO POE
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Hikvision DS-7604NXI-K1/4P 4-ch PoE 1U K Series AcuSense 4K NVR, 4-ch IP camera inputs, 40 Mbps incoming bandwidth, Smart Function, Professional and Reliability, HD Video Output, Network & Ethernet Access
| Attribute | Specification |
|---|---|
| IP Video Input | 4-ch |
| Incoming Bandwidth | 40 Mbps |
| Outgoing Bandwidth | 80 Mbps |
| HDMI Output | 1-ch, 4K (3840 ?? 2160)/30 Hz, 2K (2560 ?? 1440)/60 Hz, 1920 ?? 1080/60 Hz, 1600 ?? 1200/60 Hz, 1280 ?? 1024/60 Hz, 1280 ?? 720/60 Hz |
| VGA Output | 1-ch, 1920 ?? 1080/60 Hz, 1280 ?? 1024/60 Hz, 1280 ?? 720/60 Hz |
| Video Output Mode | HDMI1/VGA simultaneous output |
| CVBS Output | N/A |
| Audio Output | 1-ch, RCA (Linear, 1 K??) |
| Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 K??, using the audio input) |
| Decoding Format | H.265/H.265+/H.264+/H.264 |
| Recording Resolution | 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 4-ch |
| Decoding Capability | AI on: 1-ch@12 MP (30 fps)/1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps); AI off: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps) |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711ulaw/G.711alaw/G.722/G.726/AAC |
| Remote Connection | 128 |
| API | ONVIF (profile S/G); SDK; ISAPI |
| Compatible Browser | IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version |
| Network Protocol | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP???, HTTP, HTTPS |
| Network Interface | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Auxiliary Interface | SATA |
| Capacity | Up to 10 TB capacity for each HDD |
| USB Interface | Front panel: 1 ?? USB 2.0; Rear panel: 1 ?? USB 2.0 |
| Alarm In/Out | 4/1;N/A;N/A (4/1 is optional) |
| GUI Language | English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian |
| Power Supply | 12 VDC, 1.5 A |
| Consumption | ??? 10 W (without HDD) |
| Working Temperature | -10 ??C to 55 ??C (14 ??F to 131 ??F) |
| Working Humidity | 10% to 90% |
| Dimension (W ?? D ?? H) | 320 mm ?? 240 mm ?? 48 mm (12.6"?? 9.4" ?? 1.9") |
| Weight | ???1 kg (without HDD, 2.2 lb.) |
| Certification | CE, EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017, CE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS;CE, CB, KC, Reach, WEEE, RCM, UKCA, LOA |
Specification
Hikvision DS-7604NXI-K1/4P 4-ch PoE 1U K Series AcuSense 4K NVR, 4-ch IP camera inputs, 40 Mbps incoming bandwidth, Smart Function, Professional and Reliability, HD Video Output, Network & Ethernet Access
| Attribute | Specification |
|---|---|
| IP Video Input | 4-ch |
| Incoming Bandwidth | 40 Mbps |
| Outgoing Bandwidth | 80 Mbps |
| HDMI Output | 1-ch, 4K (3840 ?? 2160)/30 Hz, 2K (2560 ?? 1440)/60 Hz, 1920 ?? 1080/60 Hz, 1600 ?? 1200/60 Hz, 1280 ?? 1024/60 Hz, 1280 ?? 720/60 Hz |
| VGA Output | 1-ch, 1920 ?? 1080/60 Hz, 1280 ?? 1024/60 Hz, 1280 ?? 720/60 Hz |
| Video Output Mode | HDMI1/VGA simultaneous output |
| CVBS Output | N/A |
| Audio Output | 1-ch, RCA (Linear, 1 K??) |
| Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 K??, using the audio input) |
| Decoding Format | H.265/H.265+/H.264+/H.264 |
| Recording Resolution | 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 4-ch |
| Decoding Capability | AI on: 1-ch@12 MP (30 fps)/1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps); AI off: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps) |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711ulaw/G.711alaw/G.722/G.726/AAC |
| Remote Connection | 128 |
| API | ONVIF (profile S/G); SDK; ISAPI |
| Compatible Browser | IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version |
| Network Protocol | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP???, HTTP, HTTPS |
| Network Interface | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Auxiliary Interface | SATA |
| Capacity | Up to 10 TB capacity for each HDD |
| USB Interface | Front panel: 1 ?? USB 2.0; Rear panel: 1 ?? USB 2.0 |
| Alarm In/Out | 4/1;N/A;N/A (4/1 is optional) |
| GUI Language | English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian |
| Power Supply | 12 VDC, 1.5 A |
| Consumption | ??? 10 W (without HDD) |
| Working Temperature | -10 ??C to 55 ??C (14 ??F to 131 ??F) |
| Working Humidity | 10% to 90% |
| Dimension (W ?? D ?? H) | 320 mm ?? 240 mm ?? 48 mm (12.6"?? 9.4" ?? 1.9") |
| Weight | ???1 kg (without HDD, 2.2 lb.) |
| Certification | CE, EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017, CE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS;CE, CB, KC, Reach, WEEE, RCM, UKCA, LOA |
