Model & Classification | TP-Link Archer AX73 (AX5400) | Dual-Band Gigabit Wi-Fi 6 Router |
Wi-Fi 6 Speeds & Throughput | Aggregate Wireless Class: AX5400 (Up to 5,378 Mbps total bandwidth) 5 GHz Band: Up to 4,804 Mbps (802.11ax, HE160) 2.4 GHz Band: Up to 574 Mbps (802.11ax) Operational Modes: Wireless Router Mode & Access Point (AP) Mode |
Wireless Architecture & RF Features | Streams & Antennas: 6 Spatial Streams with 6× Fixed High-Performance External Antennas Antenna Architecture: 4T4R array with 4×4 MU-MIMO on 5 GHz (Enhanced multi-stream fault tolerance) Channel Bandwidth: Ultra-wide 160 MHz (HE160) channel support RF Optimization: Beamforming, High-Power Front-End Modules (FEM), OFDMA, Airtime Fairness, and Dynamic Frequency Selection (DFS) |
Wired Interfaces & Link Aggregation | WAN Interface: 1× Gigabit (10/100/1000 Mbps) RJ45 WAN Port LAN Interfaces: 4× Gigabit (10/100/1000 Mbps) RJ45 LAN Ports Link Aggregation: Supports Static Link Aggregation (LAG) across 2× LAN ports (up to 2 Gbps aggregated bandwidth) |
USB Storage & Media Sharing | Interface: 1× USB 3.0 Type-A Port File System Formats: NTFS, exFAT, HFS+, FAT32 Storage Services: Apple Time Machine support, Samba (SMB) Server, FTP Server, and Media Server (DLNA) |
Hardware Architecture & Controls | Processor: 1.5 GHz Triple-Core High-Performance CPU Physical Buttons: Wi-Fi On/Off, Power On/Off, LED Indicator On/Off, WPS, and Reset Power Specifications: External Power Supply (12 V ⎓ 2.5 A) |
Network Security & VPN Ecosystem | Wi-Fi Encryption: WPA, WPA2, WPA3-Personal, and WPA/WPA2-Enterprise (802.1x) Built-in VPN Server: OpenVPN Server & PPTP VPN Server Built-in VPN Client: OpenVPN Client, PPTP VPN Client, and L2TP VPN Client TP-Link HomeShield Security: Real-Time IoT Device Protection, Malicious Site Blocker, Intrusion Prevention System (IPS), DDoS Defense, and Home Network Scanner Firewall & Isolation: SPI Firewall, Access Control, IP & MAC Binding, Application Layer Gateway (ALG), and Isolated Guest Networks (1× 2.4 GHz, 1× 5 GHz) |
Software, Mesh & Management | Mesh Networking: TP-Link OneMesh™ Supported (Seamless whole-home roaming with compatible extenders) Parental Controls: HomeShield custom user profiles, content filter library, bedtime/off-time scheduling, time rewards, internet pause, and weekly/monthly usage reports Routing & Traffic: IPv4 / IPv6, QoS by Device, Port Forwarding, Port Triggering, DMZ, UPnP, Virtual Server, IGMP Proxy/Snooping IPTV bridge with Tag VLAN Setup & Cloud Services: TP-Link Tether App (iOS/Android), Web GUI, Auto Firmware Updates, DDNS (TP-Link, NO-IP, DynDNS) |
RF Output Power & Sensitivity (Test Data) | Transmit Power (CE): < 20 dBm (2.4 GHz) | < 23 dBm (5.15–5.35 GHz) | < 30 dBm (5.47–5.725 GHz) Transmit Power (FCC): < 30 dBm (2.4 GHz & 5.15–5.25 GHz & 5.725–5.825 GHz) | < 24 dBm (5.25–5.35 GHz & 5.47–5.725 GHz) Reception Sensitivity: 2.4 GHz: Down to -95 dBm (11ax HE20 MCS0) / -62 dBm (11ax HE40 MCS11) 5 GHz: Down to -97 dBm (11ac VHT20 MCS0) / -85.5 dBm (11ax HE160 MCS0) / -55 dBm (11ax HE160 MCS11) |
Physical Dimensions & Environmental | Dimensions (W × D × H): 272.5 × 147.2 × 49.2 mm (10.7 × 5.8 × 1.9 in) Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) Operating Humidity: 10% to 90% RH (non-condensing) Certifications: FCC, CE, RoHS |
| | |
