Model & Classification | TP-Link Archer BE550 (BE9300) | Tri-Band Wi-Fi 7 Multi-Gigabit Router |
Next-Gen Wi-Fi 7 Throughput | Aggregate Wireless Speed: BE9300 (Up to 9,214 Mbps across 3 bands) 6 GHz Band: Up to 5,760 Mbps (802.11be, Wi-Fi 7) 5 GHz Band: Up to 2,880 Mbps (802.11be, Wi-Fi 7) 2.4 GHz Band: Up to 574 Mbps (802.11ax, Wi-Fi 6) Operational Modes: Wireless Router Mode & Access Point (AP) Mode |
Wireless Architecture & RF Features | Streams & Antennas: 6 Spatial Streams with 6× Optimally Positioned Internal Antennas Channel Width & Modulation: Ultrawide 320 MHz Channels on 6 GHz & 4096-QAM (4K-QAM) Advanced Wi-Fi 7 Protocols: Multi-Link Operation (MLO) & Multi-Resource Units (Multi-RU) Coverage & Optimization: Beamforming, High-Power Front-End Modules (FEM), 2×2 MU-MIMO, OFDMA, Airtime Fairness, and Dynamic Frequency Selection (DFS) |
Multi-Gigabit Wired & USB Interfaces | WAN Interface: 1× 2.5 Gbps RJ45 WAN Port LAN Interfaces: 4× 2.5 Gbps RJ45 LAN Ports (Full Multi-Gigabit LAN Switching) USB Expansion: 1× USB 3.0 Type-A Port Supported File Formats: NTFS, exFAT, HFS+, FAT32 Network Storage Protocols: Samba (SMB), FTP Server, and Media Server (DLNA) |
Hardware Architecture & Controls | CPU: High-performance multi-core processor Physical Controls & Buttons: Power On/Off, Wi-Fi On/Off, LED Indicator Toggle, WPS, and Reset Power Specifications: External Power Supply (12 V ⎓ 3.3 A) |
Network Security & VPN Ecosystem | Wi-Fi Encryption: WPA, WPA2, WPA3-Personal, and WPA/WPA2-Enterprise (802.1x) Built-in VPN Server: WireGuard, OpenVPN, PPTP, and L2TP VPN Server Built-in VPN Client: WireGuard, OpenVPN, PPTP, and L2TP VPN Client TP-Link HomeShield Security: Intrusion Prevention System (IPS), Real-Time IoT Device Protection, Malicious Site Blocker, DDoS Defense, and Home Network Scanner Dedicated Isolation: Dedicated IoT Network + Isolated Guest Networks on all 3 bands (2.4 GHz, 5 GHz, 6 GHz) Firewall & Access: SPI Firewall, Access Control Lists, IP & MAC Binding, Application Layer Gateway (ALG) |
Software, EasyMesh & Smart Features | Mesh Networking: EasyMesh-Compatible (build seamless whole-home mesh roaming) Smart Home Integration: Works natively with Amazon Alexa and Google Assistant Parental Controls: HomeShield granular profiles, age-based content filtering, Bedtime/Off-Time scheduling, time rewards, and Internet pause Routing & Management: IPv4 / IPv6, QoS by Device, Port Forwarding, Port Triggering, DMZ, UPnP, IGMP Proxy/Snooping IPTV bridge with VLAN tagging Cloud & Setup: TP-Link Tether App (iOS/Android) & Web GUI, Auto Firmware Updates, DDNS (TP-Link, NO-IP, DynDNS) |
Physical Dimensions & Environmental | Dimensions (W × D × H): 76 × 231.7 × 203 mm (3.0 × 9.1 × 8.0 in) Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) Operating Humidity: 10% to 90% RH (non-condensing) Certifications: CE, FCC, RoHS |
Package Contents | TP-Link Archer BE550 Wi-Fi 7 Router External AC/DC Power Adapter RJ-45 Ethernet Cable Quick Installation Guide |
