table { border-collapse: collapse; width: 100%; margin-top: 20px; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; } td:first-child { font-weight: bold; color: #333; }
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 ?? 1520 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.2, AGC ON); B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | 1 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Blue Glass Module | To reduce ghost phenomenon |
| Lens Focal Length & FOV | 2.8 to 12 mm, horizontal FOV: 114.5?? to 41.8??, vertical FOV: 59.3?? to 23.6??, diagonal FOV: 141.1?? to 48?? 8 to 32 mm, horizontal FOV: 42.5?? to 15.1??, vertical FOV: 23.3?? to 8.64??, diagonal FOV: 49.6?? to 17.3?? |
| Focus | Auto, Semi-auto, Manual |
| Iris Type | P-iris |
| Aperture | 2.8 to 12 mm: F1.2 to F2.5 8 to 32 mm: F1.7 to F1.73 |
| DORI | Wide: 2.8 to 12 mm: D (Detect): 60 m, O (Observe): 23.8 m, R (Recognize): 12 m, I (Identify): 6 m 8 to 32 mm: D (Detect): 150.3 m, O (Observe): 59.7 m, R (Recognize): 30.1 m, I (Identify): 15 m Tele: 2.8 to 12 mm: D (Detect): 149 m, O (Observe): 59.1 m, R (Recognize): 29.8 m, I (Identify): 14.9 m 8 to 32 mm: D (Detect): 400 m, O (Observe): 158.7 m, R (Recognize): 80 m, I (Identify): 40 m |
| Illuminate | Supplement Light Type: IR Supplement Light Range: 2.8 to 12 mm: 50 m, 8 to 32 mm: 100 m Smart Supplement Light: Yes IR Wavelength: 850 nm |
| Video | Main Stream: 50 Hz: 25 fps (2688 ?? 1520, 2560 ?? 1440, 1920 ?? 1080, 1280 ?? 720) 50 fps (2560 ?? 1440, 1920 ?? 1080, 1280 ?? 720) 60 Hz: 30 fps (2688 ?? 1520, 2560 ?? 1440, 1920 ?? 1080, 1280 ?? 720) 60 fps (2560 ?? 1440, 1920 ?? 1080, 1280 ?? 720) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264, |
| Sub-stream: H.265/H.264/MJPEG, | |
| Third stream: H.265/H.264, | |
| Fourth stream: H.265/H.264/MJPEG, | |
| Fifth stream: H.265/H.264/MJPEG | |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile,Main Profile,High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR,VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region Of Interest (ROI) | 4 fixed regions for each stream |
| Target Cropping | Yes |
| E-PTZ | Support Patrol and Auto Tracking settings |
| Audio | Audio Type: Mono sound |
| Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC | |
| Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) | |
| Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz | |
| Environment Noise Filtering: Yes | |
| Network | Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets |
| Simultaneous Live View: Up to 20 channels | |
| API: Open Network Video Interface (Profile S, Profile G, Profile T, Profile M),ISAPI,SDK,ISUP | |
| User/Host: Up to 32 users | |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256 |
| Network Storage | NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), |
| Together with high-end Hikvision memory card, memory card encryption and health detection are supported. | |
| Client | iVMS-4200,Hik-Connect,Hik-Central |
| Web Browser | Plug-in required live view: IE 10, IE 11, |
| Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+, | |
| Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ | |
| Image | Image Parameters Switch: Yes |
| Image Settings: Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser | |
| Day/Night Switch: Day,Night,Auto,Schedule,Alarm Trigger,Video Trigger | |
| Wide Dynamic Range (WDR): 140 dB | |
| SNR: ??? 52 dB | |
| Image Enhancement: BLC,HLC,3D DNR,Distortion Correction,Defog | |
| Picture Overlay: LOGO picture can be overlaid on video with 128 ?? 128 24 bit bmp format. | |
| Image Stabilization: EIS | |
| Privacy Mask: 8 programmable polygon privacy masks | |
| Interface | Video Output: 1 Vp-p Composite Output (75 ??/CVBS) (Only for debugging) |
| Ethernet Interface: 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port | |
| On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB | |
| Audio: With -Y: 1 input (line in), 1 output (line out), 3.5 mm connector | |
| Alarm: 2 inputs, 2 outputs (max. 24 VDC, 1 A) | |
| RS-485: With -Y: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) | |
| Reset Key: Yes | |
| Power Output: With -Y: 12 VDC, max. 100 mA | |
| Wiegand: -Y: 1 Wiegand (CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit) | |
| Event | Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),video quality diagnosis,vibration detection |
| Smart Event: scene change detection,audio exception detection,defocus detection | |
| Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning | |
| Deep Learning Function | Perimeter Protection: Line crossing, intrusion, region entrance, region exiting |
| Road Traffic And Vehicle Detection: Smart Function: Support license plate recognition of vehicles and motorcycles (only in checkpoint scenario),Support vehicle attribute detection, including vehicle type, color, brand, driving direction, etc.,Support vehicle and non-vehicle counting,Blocklist and allowlist: up to 10,000 records,LPR Countries/Regions: 4 areas (Europe, Middle East, Asia-Pacific, Africa) and more than 124 countries/regions,Accuracy (Under recommended installation and lighting conditions): License plate recognition rate ???98%,Capture rate ???99%,Driving direction accuracy rate ???98%,Vehicle Capture Speed: Front installation in checkpoint scenario: up to 120 km/h,Side installation: up to 80 km/h,Capture Mode: License Plate and Vehicle Mode, Vehicle Priority Mode | |
| Metadata: Intrusion detection,line crossing detection,region entrance detection,region exiting detection,road traffic | |
| Parking Management | Support distant view mode and close view mode,Distant view mode: support status detection on up to 40 parking spaces, parking duration detection, and vacant parking space alarm,Close view mode: support status detection on up to 4 parking spaces, license plate recognition, parking timeout alarm, and vacant parking space alarm |
| General | Power: 12 VDC ?? 20%, 1.19 A, max. 14.28 W, three-core terminal block, PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.396 A to 0. 295 A, max. 16.8 W |
| Material: Aluminum alloy body | |
| Dimension: Without -Y: ??144 mm ?? 347 mm (??5.7" ?? 13.7\"), With -Y: ??140 mm ?? 351 mm (??5.5 ?? 13.8\") | |
| Package Dimension: 405 mm ?? 190 mm ?? 180 mm (15.9" ?? 7.5" ?? 7.1") | |
| Weight: Approx. 1950 g (4.2 lb.), With Package Weight: Approx. 3070 g (6.7 lb.) | |
| Storage Conditions: -30 ??C to 60 ??C (-22 ??F to 140 ??F). Humidity 95% or less (non-condensing) | |
| Startup And Operating Conditions: -40 ??C to 60 ??C (-40 ??F to 140 ??F). Humidity 95% or less (non-condensing) | |
| Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian | |
| General Function: Anti-banding, heartbeat, mirror, flash log, password reset via email, pixel counter | |
| Heater: Yes | |
| Device Management: Supports adding alarm box (DS-FM2466) in the LAN to expand 6 additional input and 6 output alarm interfaces | |
| Approval: EMC: FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015, Safety: UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1, Environment: CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006, Protection: IP67: IEC 60529-2013,IK10: IEC 62262:2002, Anti-Corrosion Protection: -Y: NEMA 4X (NEMA 250-2018), Automotive And Railway: EN50121-4, Other: PVC FREE |
